This luxurious 4 bedroom Mediterranean-style floor plan screams personal success and style. From the rounded front verandah, you walk straight into a breathtaking double-volume foyer with double staircases leading to the first floor. The ground floor features two big kitchens with a dry store and cold store, two living rooms, a formal dining area, a cinema theatre, a study/library, and an ensuite guestroom with its own verandah and a jacuzzi in the bathroom. A big loggia to catch the breeze runs along the whole backside of the ground floor and on the left side of the building, there is a garage with space for 2 vehicles. On the first floor, you have a family room, 4 large ensuite bedrooms with walk-in closets, and last but not least the magnificent master bedroom that comes complete with a walk-in closet and a bathroom with double vanities, shower, and jacuzzi.

Design Features

Stories – 2, Bedrooms – 4, Baths – 5, Area – 292.2 Sq/m, Length – 17.6 m, Width – 16.6 m

HM-Concept

4 Bedroom Contemporary Home Design - CD110018

4 Bedroom Contemporary Home Design - CD110018

Regular price $749.00 USD
Regular price $1,800.00 USD Sale price $749.00 USD
Sale Sold out
Shipping calculated at checkout.
Item Cost Estimate
1: Substructure
2: Superstructure
3: Roof
4: Doors
5: Windows
6: Finishes
7: Decorations
8: Plumbing Installations
9: Electrical Installations
Total Cost
View full details
  • Design Specifications

    Foundation Plan
    Floor Plans
    Roof Plan
    Detailed Sections
    Construction Details
    Elevations
    Doors and windows schedule
    Floor finishes and furniture layout plan

    Electrical schematics
    Schematic electrical layout plan
    Schematic clean water layout plan
    Schematic foul water layout plan
    Septic tank and Soak-away pit details

    Fence wall design

  • Drawing List

    All Relevant Floor Plans

    Elevations

    Sections

    All Relevant Details

    Door and Window Schedule

    Furniture Layout

    Finishes Schedule

    Structural Drawings

    Mechanical Drawings

    Electrical Drawings

    3D Perspectives

    Bill of Quantities – Without Rates

    Schedule of Materials – Without Rates

    Fire and Security Systems Layout

    -

    DRAWINGS DELIVERED IN DWG AND PDF FORMATS
